Rubber Cable
Heavy-duty rubber-sheathed flexible cables for mining, construction, and mobile equipment. Rated for harsh environments, oil resistance, and mechanical stress.
Product Gallery
Rubber Cable— Manufacturer & Supplier
Rubber-sheathed cables are designed for environments that destroy ordinary PVC cables — mining faces, construction sites, welding workshops, and mobile heavy equipment. The rubber compound (natural rubber, neoprene/chloroprene, or EPR) provides exceptional flexibility at extreme temperatures, resistance to mechanical abuse, and tolerance of oil, chemicals, and UV exposure.
Our rubber cable range includes welding cables (YH series, single-core, 200-600A), general-purpose heavy-duty flexible cables (YC series, multi-core, 450/750V), medium-duty cables (YZ series), and mining trailing cables rated up to 3.6/6 kV. Conductors are Class 5 or Class 6 flexible copper per IEC 60228, providing the tight bend radius needed for cables that move in service.
These cables serve welding equipment manufacturers, mining operations, construction companies, port crane operators, and industrial maintenance teams. We manufacture to IEC 60245, GB/T 5013, and can produce to AS/NZS 1802 for mining applications. All rubber compounds are factory-tested for tensile strength, elongation, and aging resistance per IEC 60811.
Product Capabilities
Our Rubber Cable Products
Rubber Flexible Cable (YC/YZ)
Heavy/Medium Duty Rubber Sheathed Flexible Cable
Popular Rubber Cable Models — Quick Reference
| Model | Cores × Size | Voltage | Type | Approx. OD (mm) | Weight (kg/km) |
|---|---|---|---|---|---|
| YH | 1×16 mm² | — | Welding cable | 11.0 | 185 |
| YH | 1×35 mm² | — | Welding cable | 14.5 | 370 |
| YH | 1×50 mm² | — | Welding cable | 16.5 | 510 |
| YH | 1×70 mm² | — | Welding cable | 19.0 | 700 |
| YH | 1×95 mm² | — | Welding cable | 21.5 | 940 |
| YC | 3×4+1×2.5 mm² | 450/750 V | Heavy-duty flexible | 16.0 | 310 |
| YC | 3×10+1×6 mm² | 450/750 V | Heavy-duty flexible | 20.5 | 560 |
| YC | 3×25+1×16 mm² | 450/750 V | Heavy-duty flexible | 28.0 | 1,050 |
| YC | 3×50+1×25 mm² | 450/750 V | Heavy-duty flexible | 35.5 | 1,850 |
| YZ | 3×1.5+1×1.0 mm² | 300/500 V | Medium-duty flexible | 10.5 | 130 |
Welding cable (YH) rated for intermittent duty. Current capacity depends on duty cycle — contact us for specific welding machine requirements.
Rubber Cable Types — Welding vs Heavy-Duty vs Mining
| Feature | YH (Welding Cable) | YC (Heavy-Duty Flexible) | Mining Trailing Cable |
|---|---|---|---|
| Voltage Rating | AC welding: 200V / DC welding: no rated voltage | 450/750 V | 0.66/1.14 kV – 3.6/6 kV |
| Core Count | Single-core only | 2C, 3C, 3+1C, 4C, 5C | 3+1+3 (power + earth + pilot) |
| Conductor Class | Class 5 (IEC 60228) | Class 5 (IEC 60228) | Class 5/6 extra-flexible |
| Sheath Material | Natural rubber or neoprene | Neoprene (heavy-duty) | CSP/EPR — flame retardant + oil resistant |
| Temperature Range | -30°C to +65°C | -40°C to +90°C | -40°C to +90°C |
| Key Property | Maximum flexibility, high current density | Abrasion + oil + weather resistance | Flame retardant, earth monitoring, reinforced |
| Typical Use | Arc welding machines, electrode holders | Construction sites, cranes, portable generators | Underground mining equipment, shuttle cars |
| Duty Cycle | Intermittent (60-100% depending on size) | Continuous | Continuous |
All rubber cables use Class 5 or 6 flexible copper conductors per IEC 60228. Mining cables manufactured to IEC 60245 or AS/NZS 1802.
Application Scenarios
Welding Equipment
Single-core welding cables (YH 16-120 mm²) connecting welding machines to electrode holders and work clamps. Rated for 200-600A intermittent duty with excellent flexibility for operator comfort.
Construction Sites & Mobile Equipment
Heavy-duty YC cables powering concrete mixers, tower cranes, portable generators, and temporary site distribution boards. Built to withstand dragging, crushing, and outdoor weather exposure.
Mining Operations
Trailing cables for shuttle cars, continuous miners, and longwall equipment. Reinforced sheath with earth monitoring conductors per mining safety regulations. Oil, flame, and abrasion resistant compounds.
Port & Marine Applications
Flexible power cables for ship-to-shore cranes, container handling equipment, and reeling applications. Neoprene sheath provides seawater and UV resistance for harsh coastal environments.
Why Source Rubber Cable From Us
Specialized Rubber Compounding
Our factory operates dedicated rubber cable production lines with in-house compound mixing. We control the rubber formulation for each application — natural rubber for flexibility, neoprene for oil resistance, EPR for temperature extremes.
Flexibility Testing Guaranteed
Every rubber cable batch undergoes bending test, tensile test, and elongation test per IEC 60811. Aging resistance verified through accelerated thermal aging. You receive test certificates documenting mechanical performance.
Complete Size Range in Stock Production
Welding cable from 16 mm² to 120 mm², YC from 3×2.5 to 3×95+1×50 — all on active production lines with typical lead time of 15-20 days for standard sizes. Volume orders ship faster.
Frequently Asked Questions — Rubber Cable
Q.What types of rubber cable do you produce?
We manufacture general-purpose flexible rubber cables, mining cables, welding cables, and trailing cables for heavy-duty mobile equipment.
Q.What temperature range can rubber cables withstand?
Our standard rubber cables operate from -40°C to +90°C. Silicone rubber options are available for higher temperature environments.
Q.Are your rubber cables suitable for mining applications?
Yes. We produce mining-grade rubber cables with reinforced sheath, earth monitoring cores, and compliance with AS/NZS 1802 or IEC 60245 standards.
Q.What voltage ratings are available?
Rubber cables are available from 450/750V for flexible cords up to 3.6/6kV for mining trailing cables.
Q.Do rubber cables resist oil and chemicals?
Our heavy-duty rubber cables use EPR or neoprene compounds that provide resistance to oil, chemicals, and abrasion.
Q.How can I order rubber cable from your factory?
Send us the cable type, cross-section, number of cores, voltage rating, quantity, and delivery destination. We will quote within 24 hours.
